1/4" TechniDOT™ Type A Nylon DOT Tubing
D.O.T. Nylon tubing is manufactured specifically for use in heavy vehicle pneumatic braking systems. Available in both Type A and Type B, TechniDOT™ tubing offers excellent resistance to abrasion, gasoline, diesel fuel, and commonly used road salts.
Type A tubing is a single wall extrusion less than 5/16" OD in size, and only used for accessories such as gauges.
Type B tubing is a reinforced extrusion typically over 5/16" OD in size and used to supply air within the braking system.
ATP's TechniDOT™ tubing is SAE J844 Compliant.
Specifications
|
|
Material |
Nylon 12 |
Max Working Pressure |
300 psi |
Temperature Range |
-49F to 221F |
Safety Factor |
4:1 |
