3/8″ TechniDOT™ Type B Nylon DOT Tubing
Overview
3/8" TechniDOT™ Type B Nylon DOT Tubing
| 3/8" OD DOT Type B Tubing | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Black | Green | Navy Blue | Red | Yellow | ||||||||
| 100 ft | DOTB06ABK | DOTB06AG | DOTB06ANB | DOTB06AR | DOTB06AY | |||||||
| 500 ft | DOTB06CBK | DOTB06CG | DOTB06CNB | DOTB06CR | DOTB06CY | |||||||
D.O.T. Nylon tubing is manufactured specifically for use in heavy vehicle pneumatic braking systems. Available in both Type A and Type B, TechniDOT™ tubing offers excellent resistance to abrasion, gasoline, diesel fuel, and commonly used road salts.
Type A tubing is a single wall extrusion less than 5/16" OD in size, and only used for accessories such as gauges.
Type B tubing is a reinforced extrusion typically over 5/16" OD in size and used to supply air within the braking system.
ATP's TechniDOT™ tubing is SAE J844 Compliant.
| Material | Nylon 12 |
| Max Working Pressure | 300 psi |
| Temperature Range | -49F to 221F |
| Safety Factor | 4:1 |
